| Item | MM | Rough Opening | LBS | KG | QTY | |
|---|---|---|---|---|---|---|
| ED-2002 6 X 6 | 152 X 152 | + 3/8" | 1.7 | .8 | Add To Quote | |
| ED-2002 8 X 8 | 203 X 203 | + 3/8" | 2.5 | 1.1 | Add To Quote | |
| ED-2002 10 X 10 | 254 X 254 | + 3/8" | 3.5 | 1.6 | Add To Quote | |
| ED-2002 12 X 12 | 305 X 305 | + 3/8" | 4.6 | 2.1 | Add To Quote | |
| ED-2002 14 X 14 | 355 X 355 | + 3/8" | 5.8 | 2.6 | Add To Quote | |
| ED-2002 16 X 16 | 406 X 406 | + 3/8" | 7.2 | 3.3 | Add To Quote | |
| ED-2002 18 X 18 | 457 X 457 | + 3/8" | 8.8 | 4 | Add To Quote | |
| ED-2002 20 X 20 | 508 X 508 | + 3/8" | 10.4 | 4.7 | Add To Quote | |
| ED-2002 24 X 24 | 610 X 610 | + 3/8" | 14.2 | 6.4 | Add To Quote | |
| ED-2002 24 X 36 | 610 X 915 | + 3/8" | 17 | 7.7 | Add To Quote |
Product Features
ED-2002 Access Door Specifications
Material: 18 gauge steel door and frame
Door: Flush to frame with reinforced edges
Mounting Frame: 1” wide outside flange with 1 7/16” deep mounting Frame: Knock over mounting tabs provided on 6x6, 8x8, 10x10 and 12x12
Hinge: Concealed Hinge Pin
Latch: Stainless steel slot screwdriver operated cam latch
Optional Latches/Locks: Cylinder lock and key, allen head cam latch, spanner head cam latch
Finish: 5 Stage iron phosphate preparation with prime coat of White alkyd baking enamel
See the Datasheet for more product information.
